MS100 Mower Kit
Buy the FJD MS100 guidance kit for 3- and 5-gang golf and sports mowers: straight, curve and pivot modes with centimetre-level RTK accuracy.
- Product Category : Shop all Mower Kits
- Price Range : €8,043
- Availability : In stock · ships from Frankfurt (Oder), Germany
- Shipping : Europe and worldwide – see our shipping policy · 30-day returns
- Select Varient :
Features
Explore Product Features
Simple Installation
Precision Accuracy (±2.5cm)
Lane Keeping Mode
Curve Mode
Pivot Mode
Support OTA
U-Turn
Slope Compensation
FJD MS100 Mower Kit: Driving Assistance for Golf and Sports Turf Mowers
The FJD MS100 Mower Kit is a retrofit driving-assistance system for mainstream three- and five-gang golf course mowers. It brings the same kind of satellite guidance used in tractor autosteering to fairways and sports pitches. The kit steers the mower along the planned line while the operator controls speed with the pedal, so every pass is straight and stripes are even.
Greenkeepers, sports ground managers and turf contractors who want straighter lines, fewer overlaps and less tiring days on the mower are the main users. If you want to buy FJD MS100 for an existing fleet, or you are comparing mower guidance kits for sale in Europe, the MS100 lets you upgrade the mowers you already own instead of replacing them.
Key Features and Benefits
Three driving modes
Choose straight lines, curves or pivots, all of which can be customised. This covers classic striped fairways, curved designs that follow the shape of the hole, and circular patterns.
Centimetre-level guidance
A high-precision GNSS positioning system gives centimetre-level accuracy, according to FJD. This cuts overlap between passes, so less fuel and time go into mowing the same strip twice.
Adapts to uneven ground
The steering system adjusts automatically to contours and undulating ground, which helps keep lines true on real-world fairways rather than only on flat pitches.
Reusable guidance lines
Guidance line profiles can be saved and used again. Plan a pattern once and repeat it every time you mow, or alternate saved patterns to vary the stripe direction.
Easier operator days
Because the kit handles the steering, the operator can focus on speed, cut quality and safety, which reduces fatigue over long shifts.
How the MS100 Works
The system is built around an Android control terminal with a 10.1-inch display, an electric steering wheel fitted to the mower, a GNSS antenna, an IMU and an angle sensor. The antenna receives GPS, GLONASS and BeiDou signals, and RTK corrections from a base station or network refine the position to centimetre level. The IMU and angle sensor measure the mower's heading, tilt and steering angle, and the terminal sends commands to the electric steering wheel to keep the mower on the chosen line. The terminal has 4G connectivity and dedicated ports for a radar, GNSS antennas and a base station.
Applications: Who Should Buy the FJD MS100?
- Golf courses mowing fairways with three- or five-gang reel mowers.
- Sports fields and stadiums where straight, presentable stripes matter for matches and broadcasts.
- Turf contractors who want a GPS guidance kit that moves the value of precision farming equipment onto amenity turf.
- Venues with less experienced staff, where guidance helps new operators produce consistent results quickly.
Technical Specifications
| Component | Specification |
|---|---|
| Control terminal | Android, 10.1-inch display, 1280 × 800, IP65, 10–30 V input, 4G/3G/2G |
| Terminal dimensions | 300 × 190 × 43 mm |
| Terminal interfaces | Radar ×1, 4G ×1, GNSS ×2, base station ×1 |
| Electric steering wheel | 370 × 370 × 123 mm, IP66, 12/24 V DC |
| GNSS signals | GPS L1/L2, GLONASS L1/L2, BDS B1/B2/B3 |
| Angle sensor | IP67, −40 °C to 85 °C |
| Driving modes | Straight, curve, pivot |
Compatibility and Related FJD Products
FJD designs the MS100 for mainstream three- and five-gang golf mowers. Because fittings vary between models, please send us your mower make and model so we can check compatibility before you order. For RTK corrections you can use an FJD base station such as the FJD V1 portable base station or the fixed FJD N20, or a private network built with the FJD Trion N10 CORS System. For fully autonomous mowing, have a look at the FJD RM21 Robotic Mower and the FJD Z42P Smart Lawn Mower.
Browse all our robotic mower kits and line markers, or read which GPS accuracy your farm needs before you choose.
Why Buy the FJD MS100 from CMC SmartFarm
CMC SmartFarm supplies FJD guidance systems and turf robots to customers across Europe and other regions, with prices in euros and worldwide shipping. Before you buy, our team can give expert advice on mower compatibility and RTK correction options. For the current FJD MS100 price delivered to your country, send a quote request through our contact page.
Buy the FJD MS100 Mower Kit Online: Quotes, Wholesale Prices and Delivery
Buy the FJD MS100 Mower Kit online at CMC SmartFarm, or request a price quotation if you are comparing several FJD mowers for your site. The FJD MS100 Mower Kit is made by the manufacturer FJDynamics, and CMC SmartFarm is your supplier of FJD robotic and electric mowing equipment.
Golf courses, sports clubs, councils, landscaping companies and garden machinery dealers can order for commercial use and ask for a wholesale price on bulk orders. Each B2B quotation includes delivery to your site. We arrange shipping across the European Union and worldwide, so businesses and private buyers in any country can order the FJD MS100 Mower Kit.
Frequently Asked Questions
Does the MS100 make my mower fully autonomous?
No. It is a driving-assistance kit: it steers, while the operator stays on the mower and controls speed.
Which mowers does it fit?
FJD states it is designed for mainstream three- and five-gang golf mowers. Contact us with your model to confirm.
Do I need an RTK base station?
Centimetre-level guidance needs RTK corrections, either from a base station such as the FJD V1 or from a network service. We can advise on the best option for your site.
Is the MS100 the best mower guidance kit for fairways?
If you want straight, repeatable stripes from the mowers you already own, the MS100 is a strong choice. Ask us for advice on your fleet.
