V1 Base Station
Buy the FJD V1 portable GNSS RTK base station: all constellations, cm-level accuracy, around 5 km range, 10-hour battery and IP67 rating. No subscription.
- Product Category : Shop all Base Stations
- Price Range : €2,199
- Availability : In stock · ships from Frankfurt (Oder), Germany
- Shipping : Europe and worldwide – see our shipping policy · 30-day returns
- Select Varient :
Features
Explore Product Features
Global Constellation Coverage
Wide Work Range
CM-level Accuracy
Long Battery Life
IP67 Rating
Lightweight & Durable
The FJD V1 Base Station is a compact, portable GNSS RTK receiver that gives your tractors, mowers and survey equipment their own source of centimetre-level correction data, wherever you happen to be working. It suits farmers, contractors and landscaping teams who want reliable RTK accuracy without depending on a mobile network or a paid correction subscription, and who need a base they can set up quickly, take down at the end of the day and move to the next field or site.
If you are looking for a portable RTK base station for an FJD autosteering system or other GNSS-guided machinery, the V1 is designed to be light, rugged and simple to configure from a smartphone. You can buy the FJD V1 from CMC SmartFarm with delivery across Europe and worldwide.
Key features and benefits
All-constellation, multi-frequency tracking
The receiver has 965 channels and tracks GPS, BeiDou (BDS-2 and BDS-3), GLONASS, Galileo, QZSS and SBAS signals across multiple frequencies. Using many satellites at once helps the base hold a stable fix near hedgerows, tree lines and buildings, and FJD highlights strong resistance to interference.
Built-in radio with a useful working range
Corrections are broadcast over a built-in UHF radio. In ordinary conditions FJD quotes a working range of around 5 km, which may vary between roughly 3 and 8 km depending on terrain and interference. Where you need more reach, an optional FJD external radio can extend the range to as much as 30 km in ideal conditions.
A full working day on one charge
A 6500 mAh battery typically runs the V1 for about 10 hours in base station mode. For longer jobs you can power it from an external energy storage unit, from a 9–32 V DC supply through the aviation plug, or keep it running on mains power. It also charges via 30 W USB PD fast charging.
Tough enough for the field
At around 1 kg, the V1 is easy to carry, yet FJD has put it through IP67 testing and a 1.5 m drop test. It is built to resist corrosion and operates from -30 °C to +60 °C, so it can stay out through cold spring mornings and hot harvest days.
Quick setup from your phone
A companion app for Android and iOS lets you configure the base station in a few taps, check its status and change settings without connecting a laptop.
How the V1 works
An RTK base sits at a fixed point and continuously measures the difference between its known position and what the satellites report. It then transmits those corrections by radio to the rover receivers on your machines, which apply them to reach centimetre-level accuracy. With the V1 the whole process runs locally: mount the receiver on its tripod, power it on, set it up in the app and your vehicles start receiving corrections over the radio link. No internet connection is needed, which makes it a practical choice in areas with patchy mobile coverage.
Precision GPS receiver for agriculture: who should buy it
- Precision agriculture: drilling, spraying, cultivation and bed forming with GPS autosteering on arable, vegetable and mixed farms, in every season.
- Small and medium farms: an affordable way to get your own corrections for one or a few tractors without network fees.
- Contractors and service providers: carry the base from customer to customer and set it up in minutes.
- Landscaping and turf: precise mowing and line work with GNSS-guided machines.
- Construction and geospatial work: consistent RTK positioning across a project.
Technical specifications
| Specification | Value |
|---|---|
| Channels | 965 |
| Constellations | GPS, BDS-2, BDS-3, GLONASS, Galileo, QZSS, SBAS (some signals require firmware upgrade) |
| RTK accuracy (RMS) | Horizontal 8 mm + 1 ppm, vertical 15 mm + 1 ppm |
| Data formats | RTCM 2.x, RTCM 3.x, NMEA-0183 |
| Built-in radio | 410–470 MHz / 840.5–845 MHz and 902–928 MHz, 0.5 W / 1 W |
| Radio protocols | TrimTalk, TrimMark III, TT450S, TRANSEOT, Satel 3AS 4FSK |
| Working range | About 5 km in ordinary conditions |
| Battery | 6500 mAh, typically 10 hours |
| Power input | USB PD 30 W fast charging; aviation plug 9–32 V DC |
| Size / weight | Ø162 × 86 mm / 1.07 kg |
| Protection | IP67 |
| Operating temperature | -30 °C to +60 °C |
What's included and compatible products
FJD lists the V1 GNSS receiver and a V1 tripod kit as standard items; please check the exact package contents with us before ordering. Optional add-ons include the FJD external radio for longer range and the FJD PONY 500 power unit for extended operating time. Thanks to its standard RTCM output and common radio protocols, the V1 can serve a wide range of rovers, including FJD guidance products such as the FJD AT2 Auto Steer System; ask us to confirm the right radio settings for your machines. For permanent or larger installations, compare it with the FJD N20 Fixed High Power GNSS Station and the FJD Trion N10 CORS System.
See the full range of RTK base stations, or learn RTK vs GPS for agriculture.
Why buy the FJD V1 Base Station from CMC SmartFarm
The FJD V1 Base Station is for sale online at CMC SmartFarm, ready to order with prices in euros. CMC SmartFarm supplies precision farming equipment to customers internationally, with all prices shown in euros. Our team is happy to advise you before you buy, from choosing between a portable and a fixed RTK base station to checking radio compatibility with your existing receivers. For the FJD V1 price delivered to your country, or for a quote on a complete guidance package, send us a request through our contact page.
Order the FJD V1 Base Station: Supplier Prices, Bulk Quotes and Shipping
Looking to purchase the FJD V1 Base Station? Buy it online here or ask for a price quotation if you need several stations or a complete RTK setup. FJDynamics is the manufacturer, and CMC SmartFarm is your supplier of FJD positioning equipment, with prices in euros.
Dealers, contractors, cooperatives and other businesses building their own correction network can request a wholesale price for a bulk order. B2B customers receive one quotation covering the stations, any accessories and delivery. We ship the FJD V1 Base Station across Europe and worldwide, so farms and commercial operators in any country can order with confidence.
Frequently asked questions
Do I need a mobile signal to use the V1?
No. The V1 sends corrections over its built-in radio, so it works in fields without internet access. The app is only used for configuration.
How far will the corrections reach?
Around 5 km in normal conditions, varying with terrain and interference. An optional FJD external radio can extend this to up to 30 km in ideal conditions.
Can it run longer than one day?
Yes. Beyond the internal battery's typical 10 hours, you can connect an external power source or mains power for continuous operation.
Is it suitable for more than one tractor?
Yes. Any rover within radio range that uses a compatible protocol can receive the same corrections.
