AS2 Steer-Ready Autosteering System
Buy the FJD AS2 plug-and-play autosteering for steer-ready tractors. Controls the hydraulic valves directly for 2.5 cm RTK accuracy and automatic U-turns.
- Product Category : Shop all Autosteer Systems
- Price Range : €5,847
- Availability : In stock · ships from Frankfurt (Oder), Germany
- Shipping : Europe and worldwide – see our shipping policy · 30-day returns
- Select Varient :
Features
Explore Product Features
Designed for Steer-ready Vehicles
Plug and Play
Original Configuration
2.5cm RTK Accuracy
Enhanced Terrain Adaptability
Versatile Guidance Line Options
Automatic U-turn
GIS Information Transfer
FJD AS2 Steer-Ready Autosteering System: plug-and-play guidance for steer-ready tractors
The FJD AS2 Steer Ready Autosteering System is designed for tractors and other agricultural machines that left the factory "steer ready", meaning they already have the hydraulic steering valves and wiring needed for autosteer but no guidance system activated. Instead of fitting an electric steering wheel or an extra hydraulic valve, the AS2 plugs into the machine's reserved steer-ready port and controls the original factory valves directly. It is available as the AS2 and the higher-specification AS2 Max, each in CANBUS and non-CANBUS versions.
For farmers who own a steer-ready machine and want to unlock its potential, the AS2 offers a lower-cost path to GPS autosteering than upgrading to a factory guidance package.
Key features and benefits
Plug and play installation
The system connects to the steer-ready port, takes power from the cab power outlet and uses the tractor's own steering valves. No steering wheel replacement, no additional valve and no change to the original configuration are needed, and implements can be swapped without repeated calibration.
Up to 2.5 cm accuracy
With network RTK or an RTK base station, FJD rates accuracy at up to 2.5 cm. Free PPP and SBAS corrections are also supported, giving decimetre-level accuracy where RTK is not available.
Original steering wheel stays in place
The wheel stays still while the system steers, and turning it hands control straight back to the driver in an emergency.
Smart and basic U-turns
Smart U-turn plans the turning path and can close headlands, while Basic U-turn simply moves the machine across to the adjacent row.
Large touchscreen terminal
FJD's AS2 page highlights a 12-inch high-definition touchscreen with split-screen multitasking and, according to FJD, 46% more viewing area. Please ask us which terminal comes with the AS2 or AS2 Max version you choose.
How it works
A GNSS receiver integrated with the control terminal calculates the machine's position using multiple satellite constellations and correction sources. The terminal compares the position with the selected guidance line and sends steering commands through the tractor's steer-ready interface, so oil flow is controlled by the factory hydraulic valves. Guidance patterns include straight lines, curves, A+ lines and pivots, plus special patterns for headlands, diagonal harrowing and tramlines. Field data can be shared between terminals, transferred as GIS information, or synchronised with a farm management system so that pre-planned boundaries and guidance paths can be executed in the field.
Applications and who should buy it
The AS2 is ideal for owners of steer-ready tractors and other steer-ready agricultural machinery who want precision farming equipment for harrowing, planting, spraying and harvesting. It suits large arable farms and contractors with modern fleets, as well as smaller farms that have bought a used steer-ready tractor and do not want to pay for a factory activation. Because there is no aftermarket wheel, the cab layout stays exactly as the manufacturer intended.
Technical specifications
- Accuracy: up to 2.5 cm with network RTK or a base station; decimetre level with PPP/SBAS
- Connection: steer-ready port, CANBUS or non-CANBUS versions
- Power: direct from the in-cab power source
- Display: high-definition touchscreen with split-screen
- Guidance patterns: straight, curve, A+, pivot, headland, diagonal harrowing, tramline
- Versions: AS2 and AS2 Max
Compatibility and related FJD products
The AS2 works with steer-ready machinery; exact compatibility and available features depend on the brand, model and configuration, so please send us your machine details before ordering. Optional accessories include the FJD ISOBUS kit for controlling several implements from one terminal, the FJD Wi-Fi Camera with infrared night vision, the FJD Easy Control wireless keypad and the FJD Easy Switch for manual and auto changeover. Owners can later upgrade to the FJD AT2 Max. For tractors without steer-ready hardware, the FJD AT2 electric wheel kit or the FJD AH2 hydraulic kit may be a better fit.
Browse all our tractor guidance systems, or learn how tractor autosteer works.
Why buy the FJD AS2 from CMC SmartFarm
The FJD AS2 Steer Ready Autosteering System is for sale online at CMC SmartFarm, ready to order with prices in euros. CMC SmartFarm in Frankfurt (Oder), Germany, sells FJD autosteering systems throughout Europe and offers worldwide shipping, with all prices in euros. Steer-ready compatibility can be confusing, so we are happy to check your machine and recommend the right AS2 variant before you buy FJD AS2 equipment. To get the FJD AS2 price for your country or a quote for both the AS2 and AS2 Max, contact us via our contact page.
Buy the FJD AS2 Online: Price Quotation, Wholesale and Delivery
You can buy the FJD AS2 online at CMC SmartFarm and order it directly from this page, or request a price quotation for your exact configuration through our contact page. The system is made by the manufacturer FJDynamics, and CMC SmartFarm acts as your supplier of FJD precision farming equipment from Germany.
We work with commercial customers as well as individual farmers. Agricultural contractors, farm groups, machinery dealers and resellers can ask for a wholesale price on a bulk order for a whole fleet of tractors, and every B2B quotation includes delivery costs to your country. We arrange delivery and shipping across Germany, the European Union and worldwide, so the FJD AS2 can reach your farm wherever you work.
Frequently asked questions
What does "steer ready" mean?
It means the machine was built with factory steering valves and wiring prepared for autosteer, so a system like the AS2 can control them directly.
Do I need to replace my steering wheel?
No. The original wheel stays, and turning it takes manual control at any time.
CANBUS or non-CANBUS: which do I need?
It depends on your tractor's steer-ready interface. Send us the make, model and year and we will advise.
Will it work if RTK is not available?
Yes, with free PPP and SBAS corrections at decimetre-level accuracy.
