AT2 Max Autosteering Kit
Buy the FJD AT2 Max autosteering kit with 12.1-inch display, RTK accuracy, free PPP & SBAS, automatic U-turn and ISOBUS. Shipped worldwide.
- Product Category : Shop all Autosteer Systems
- Price Range : €6,621
- Availability : In stock · ships from Frankfurt (Oder), Germany
- Shipping : Europe and worldwide – see our shipping policy · 30-day returns
- Select Varient :
Features
Explore Product Features
RTK Accuracy
12.1-Inch Display
High-Speed CPU
Free PPP & SBAS
Automatic U-turn
New Steering Wheel
Online Support
ISOBUS
FJD AT2 Max Autosteering Kit: the flagship of the AT2 series
The FJD AT2 Max Autosteering Kit is the top model in FJDynamics' AT2 family of retrofit guidance systems, built for farmers who want the largest screen, the fastest terminal and the widest set of functions FJD offers for an electric steering wheel kit. It turns a conventional tractor into a GPS autosteering system with RTK guidance, automatic headland turns and ISOBUS implement control, all run from one rugged in-cab terminal. If you are comparing tractor autosteer kits and want the most capable option in the AT2 range, this is the model to look at.
Compared with the standard FJD AT2, the Max version brings a bigger display, a considerably quicker processor and more memory, which makes a real difference when you run guidance, ISOBUS screens and a camera feed at the same time.
Key features and benefits
12.1-inch split-screen display
The terminal uses a 12.1-inch capacitive touchscreen with a resolution of 1280 x 800 pixels. According to FJD it offers around 46% more visible area than the standard AT2 and can be split so that guidance, implement data and other windows sit side by side.
High-speed CPU and upgraded memory
FJD states that computing performance is 170% of the AT2 and that memory has been doubled. In daily use this means quicker loading of fields and lines and smoother switching between screens.
Free PPP and SBAS backup
RTK corrections give the highest accuracy, but mobile coverage and radio links are not perfect everywhere. If RTK drops out, the AT2 Max switches to PPP positioning and returns to RTK automatically once corrections are available again, so work does not have to stop.
Automatic U-turn
The system plans turning paths at the end of each run, reducing the amount of manual steering on headlands and helping drivers start the next pass on line.
New steering wheel
The kit comes with a redesigned electric steering wheel with a leather rim for better grip and comfort over long days, driven by FJD's latest motor.
ISOBUS on the same screen
A full-screen ISOBUS Universal Terminal view can display up to 24 sections at once, so compatible sprayers and spreaders can be managed from the autosteer terminal instead of a separate monitor.
How the AT2 Max works
A multi-constellation GNSS receiver on the cab roof tracks GPS, GLONASS, BeiDou and Galileo signals and receives SBAS corrections. Combined with RTK corrections from a base station or an NTRIP network, it calculates the tractor's position very precisely. A built-in IMU measures roll and pitch so the system can correct for slopes. The terminal compares this position with your chosen guidance line and sends commands to the electric steering wheel, which turns the steering column directly. You can create straight, curved, pivot and mixed lines, generate tramlines and headlands from field boundaries, and pick inflection points for diagonal harrowing in polygonal fields. Supported tractor parameters can be imported with one click, and FJD provides over-the-air (OTA) online support.
Applications: who should buy the FJD AT2 Max
The AT2 Max suits arable and mixed farms that want precision farming equipment for drilling, planting, spraying, spreading, harrowing and harvesting. It is a strong choice for contractors who move between many fields and need fast processing and clear split-screen views, and for farms that already run ISOBUS implements and want one terminal in the cab. Night work is easier with the optional wired infrared camera, and drivers who need to reach controls quickly can add the Easy Control keypad.
Technical specifications
| Item | Specification |
|---|---|
| Display | 12.1-inch capacitive touchscreen, 1280 x 800 pixels, 500 nits |
| Terminal dimensions | 290 x 196 x 25 mm |
| Terminal protection | IP67 |
| Input voltage | 9-36 V |
| GNSS signals | GPS, GLONASS, BDS, Galileo, SBAS |
| Receiver protection | IP66 |
| Steering wheel | 410 x 410 x 135 mm, IP65 |
| Operating temperature | -20 °C to 70 °C |
Compatibility and related FJD products
The AT2 Max is a retrofit kit for a wide range of tractors; tell us your make and model so we can check the fit. It works with FJD RTK base stations such as the FJD V1 Base Station and the FJD Trion N10 CORS System, and with accessories including the FJD ISOBUS connection kit, the wired infrared night-vision camera and FJD Easy Control. Owners of the FJD AT2, FJD AS2 or FJD AH2 can move up to the AT2 Max with an upgrade package.
Browse all our tractor autosteer kits, or read how tractor autosteer works before you choose.
Why buy the FJD AT2 Max from CMC SmartFarm
The FJD AT2 Max Autosteering Kit is for sale online at CMC SmartFarm, ready to order with prices in euros. CMC SmartFarm, based in Frankfurt (Oder), Germany, sells FJD precision farming equipment across Europe and offers worldwide shipping. All prices are shown in euros. Before you buy FJD AT2 Max equipment, our team can talk through your tractor, correction source and implements so you order the right configuration. For the FJD AT2 Max price delivered to your country, or for a quote covering several kits, please use our contact page.
Buy the FJD AT2 Max Online: Price Quotation, Wholesale and Delivery
You can buy the FJD AT2 Max online at CMC SmartFarm and order it directly from this page, or request a price quotation for your exact configuration through our contact page. The system is made by the manufacturer FJDynamics, and CMC SmartFarm acts as your supplier of FJD precision farming equipment from Germany.
We work with commercial customers as well as individual farmers. Agricultural contractors, farm groups, machinery dealers and resellers can ask for a wholesale price on a bulk order for a whole fleet of tractors, and every B2B quotation includes delivery costs to your country. We arrange delivery and shipping across Germany, the European Union and worldwide, so the FJD AT2 Max can reach your farm wherever you work.
Frequently asked questions
What is the difference between the AT2 and the AT2 Max?
The AT2 Max has a larger 12.1-inch display, a faster processor, more memory, a new steering wheel and a full-screen ISOBUS view, making it the most capable AT2 model.
Does it keep working if I lose RTK signal?
Yes. It falls back to PPP positioning and switches back to RTK automatically when corrections return.
Can I control my sprayer from the terminal?
With a compatible ISOBUS implement and the FJD ISOBUS connection kit, the terminal can act as the universal terminal for it.
Is this the best tractor autosteer kit for night work?
Its large screen and support for an infrared wired camera make it well suited to long shifts and work after dark.
