AH2 Hydraulic Autosteer Kit
Buy the FJD hydraulic autosteering kit for large tractors that keep their original steering wheel. 2.5 cm RTK accuracy and stable control on rough terrain.
- Product Category : Shop all Autosteer Systems
- Price Range : €5,933
- Availability : In stock · ships from Frankfurt (Oder), Germany
- Shipping : Europe and worldwide – see our shipping policy · 30-day returns
- Select Varient :
Features
Explore Product Features
No Replacement Required
Enhanced Terrain Adaptability
Extensive Vehicle Compatibility
2.5cm RTK Accuracy
Guidance Line Management
Automatic U-turn
FJD Hydraulic Autosteer Kit (AH2 / AH2 Max): precision guidance through the steering hydraulics
The FJD Hydraulic Autosteering Kit steers your machine by regulating steering oil through a proportional hydraulic valve, rather than turning the steering column with an electric wheel. That means the original steering wheel stays in place and the system has the strength and stability needed for large, high-horsepower tractors and other heavy vehicles working in demanding terrain. It is offered as the FJD AH2 with a 10.1-inch terminal and the FJD AH2 Max with a 12.1-inch terminal.
If you run big tractors, work on hills or rough ground, or simply prefer to keep the factory wheel, a hydraulic tractor autosteer kit is often the better choice than an electric steering wheel system.
Key features and benefits
- No steering wheel replacement: the kit works with the existing wheel, so the cab stays as the manufacturer built it.
- 2.5 cm steering accuracy: with RTK corrections, FJD states 2.5 cm steering accuracy.
- Built for tough terrain: because the wheel does not rotate during autosteer, the system copes well with heavy work, slopes, rolling fields and rough ground.
- Wide vehicle compatibility: four compact hydraulic valve options are available, and according to FJD the kit suits over 95% of vehicles, especially high-horsepower machines.
- Valve protection: the 30 L/min valve includes a built-in 6-way, 2-position valve that only routes oil through the proportional valve core during automated driving. FJD says it works with both reactive and non-reactive steering.
- Automatic U-turns: Smart U-turn plans turns and closes headlands; Basic U-turn performs Ω and fishtail turns to reach the next row.
- Two screen sizes: the AH2 Max terminal gives about 46% more viewing area than the AH2, and both support split-screen.
How hydraulic autosteering works
A multi-constellation GNSS receiver on the roof determines the vehicle's position, and RTK corrections from a base station or network refine it to centimetre level. The control terminal compares this position with the selected guidance line and sends commands to the proportional valve, which adds or removes oil flow in the steering circuit. An angle sensor and a pressure sensor in the steering system provide feedback to the controller so the vehicle follows the line smoothly. Guidance lines can be managed on the terminal, and the system can connect to a farm management system to sync operational data and run pre-planned boundaries and guidance paths.
Applications: who should buy the FJD AH2
This hydraulic GPS autosteering system is aimed at large farms, contractors and operators of high-horsepower tractors and other large vehicles. Typical jobs include harrowing, planting, spraying and harvesting. It is particularly useful on hilly or uneven land where an electric wheel may struggle, and in operations where keeping the original steering feel matters to drivers.
Technical specifications
| Component | Specification |
|---|---|
| Steering accuracy | 2.5 cm (RTK) |
| Display | AH2: 10.1-inch; AH2 Max: 12.1-inch |
| Control terminal | 275 x 180 x 40 mm, 9-36 V, 4G/3G/2G, IP65 |
| GNSS receiver | GPS, GLONASS, BDS, Galileo, QZSS; IP66 |
| Proportional valve | 30 or 60 L/min, 12 V, open or closed centre |
| Pressure sensor | G 1/4 thread, 0-5 V DC output, 3000 psi range |
| Angle sensor | IP67, -40 °C to +85 °C |
What's in the system and related FJD products
The system is built around the control terminal, the GNSS receiver, the proportional valve, the angle sensor and the pressure sensor. Compatible accessories include FJD ISOBUS for running several implements from one terminal, FJD Easy Switch, FJD Easy Control and the FJD Wi-Fi Camera with 1080P video and infrared night vision. RTK corrections can come from an FJD base station or an NTRIP service. AH2 owners can later move to the FJD AT2 Max platform with an upgrade package. If your tractor is steer ready from the factory, the FJD AS2 may be simpler; for smaller tractors the FJD AT2 electric kit is another option.
See the full range of auto steer systems for tractors, or read our guide to tractor autosteer before you choose.
Why buy the FJD AH2 from CMC SmartFarm
The FJD Hydraulic Autosteering Kit is for sale online at CMC SmartFarm, ready to order with prices in euros. CMC SmartFarm, based in Frankfurt (Oder), Germany, supplies FJD precision farming equipment across Europe and offers worldwide shipping, with all prices listed in euros. Hydraulic kits depend on your valve type and oil flow, so we offer expert advice before purchase to help you choose between the AH2 and AH2 Max and the correct valve. For the FJD AH2 price delivered to your country or a tailored quote, please get in touch through our contact page.
Buy the FJD AH2 Hydraulic Autosteer Kit Online: Price Quotation, Wholesale and Delivery
You can buy the FJD AH2 Hydraulic Autosteering Kit online at CMC SmartFarm and order it directly from this page, or request a price quotation for your exact configuration through our contact page. The system is made by the manufacturer FJDynamics, and CMC SmartFarm acts as your supplier of FJD precision farming equipment from Germany.
We work with commercial customers as well as individual farmers. Agricultural contractors, farm groups, machinery dealers and resellers can ask for a wholesale price on a bulk order for a whole fleet of tractors, and every B2B quotation includes delivery costs to your country. We arrange delivery and shipping across Germany, the European Union and worldwide, so the FJD AH2 Hydraulic Autosteering Kit can reach your farm wherever you work.
Frequently asked questions
Should I choose hydraulic or electric autosteering?
Hydraulic suits large, high-horsepower vehicles and difficult terrain and keeps the original wheel; electric steering wheel kits such as the FJD AT2 replace the wheel on the column and suit a wide range of standard tractors.
What is the difference between the AH2 and AH2 Max?
The main difference listed by FJD is the terminal: 10.1 inches on the AH2 and 12.1 inches on the AH2 Max.
Which valve do I need?
It depends on your steering circuit (open or closed centre) and oil flow. Send us your tractor details and we will help.
Can I control implements from the terminal?
Yes, with compatible ISOBUS implements and the FJD ISOBUS accessory you can run several implements from one terminal.
